ICS ZQ-T8650 i5 1035G1 Touch POS

Downloads

File	Size	Download
zq-t8650-touch-pos-i5-1035-datasheet.pdf	370.77KB	Download

Description

ICS ZQ-T8650 15'' CAP, i5 1035G1, FANLESS, USB, RS232, LAN, AUDIO, VGA, HDMI Touch POS

15" PC-based Touch POS Terminal. Monitor housing made by aluminum, with Intel Core i5 1035G1, 1.00GHz up to 1.19GHz FANLESS with different interfaces. Various options of peripherals and multi-point capacitive touch solution. The inside is very neat. Rotatable and inseparable cable cover. Easy to add customer display or secondary monitor. Peripheral connection cables could easily go through the base and be fixed well. Pluggable Dallas Lock / MSR modules without cable connection.

ICS

Specifications

Touch Systems
Monitor	15" Capacitive touch panel 10 points
CPU	Intel Core i5-1035G1 (10th GEN) 1.00GHz up to 1.19GHz FANLESS
Memory	1 X SLOT 8GB DDR4 SO DIMM up to 64GB
Disk	1 X SLOT 256GB MSATA 2,5
Operating System	Windows 10 IoT. Compatible OS Windows 11 / IoT
Resolution	1024 x 768
USB Ports	6 X USB (2 X 3.0 , 4 X 2.0)
Serial Ports	2 X RJ48 (2 X RS232)
Ethernet Ports	1 X RJ45 (10/100/1000 Mbps)
Additional Ports	1 X VGA , 1 X 3.5 mm Line-out , 1 X 3.5 mm Mic-In
Power supply	1 X Power Supply 12V 7A INPUT, 1 X Power Supply 12V 7A OUTPUT
Temperature/ Humidity	Operation Temperature 0 - 40°C . Storage : -20~60°C. Humidity 0 - 95%
Dimensions/ Weight	446 x 118 x 388mm/ 9kg.
Additional features Touch Touch Systems	Audio: Realtek ALC 662HD (on board), Extended Slots: 1 x MINI-PCIE (for 4G/WIFI), 1 x SIM (on board), Customer Display: VFD or 9.7". WALL MOUNT Optional 75x75.
