Tablet POS 10.1'' Elo

Tablet POS 10.1'' Elo

Downloads

File	Size	Download
elo-brochure_elo_tabelt.pdf	851.19KB	Download
ELO_Tablet_DS_16102AES00060.pdf	212.99KB	Download

Description

Tablet POS 10.1'' Elo

Rugged & connected with Windows / Intel architecture. Integrated MSR, Barcode Reader, and Smart Card Reader, 10.1” PCAP touch screen 1366x768 LCD Display, Wi-Fi, Bluetooth, NFC and RFID. Docking station with battery charging location, Ethernet, 3 x USB, and VGA, USB connectivity to external peripherals. MTBF: 50,000 hours demonstrated.

ELO

Specifications

Tablet POS
Monitor	10.1", 1366x768 LCD on tablet; VGA DB15 output via Docking Station.Projected Capacitive (PCAP) Multi Touch (4 touch)
CPU	Intel Atom N2600 Dual Core 1.6 GHz
Memory	2GB DDR3 – 1066 MHz
HDD	32GB MSATA SSD
Operating System	Windows Embedded 7 Standard (Also licensed for Windows Embedded 8 Standard), Windows 8.1
Resolution	1366 x 768
Interface	Wi-Fi (802.11 b/g/n), Bluetooth (4.0), NFCIP-1 Reader /Writer
USB Ports	1 x USB 2.0 on tablet; 3 x USB 2.0 on Docking Station
Ethernet Ports	1 x LAN RJ45 (10/100Mbps) (when docked in Docking Station)
Additional Ports	Audio Ports: 3.5mm audio mic/earphone hidden/ protected cover. Speakers: Internal speaker.
Power supply	Power Adapter AC 120/220V (50/60 Hz), 36W/ Typical Power Consumption: (without peripherals) 7W - estimated battery run time up to 7 hours.
Temperature/ Humidity	Temperature Operating: 32°F to 104°F (0°C to 40°C); Storage: -4°F to 140°F (-20°C to 60°C)/ Humidity (non-condensing) Operating: 20% to 80% Storage: 5% to 95%
Dimensions /weight	Tablet: 11.52" x 0.79" x 8.17" (292.61mm x 20.07mm x 207.52mm); Dock: 11.5" x 7.1" x 7.8" (292.1mm x 180.34mm x 198.12mm)/ Tablet: 2.5 lbs (1.13 kg); Docking: 2.8 lbs (1.27 kg)
Additional features Tablet	Chipset: Intel NM10/ BIOS: Phoenix/ Mounting Options: VESA mount via optional accessory bracket (E624438)/ MTBF: 50,000 hours demonstrated/ Sealing: IP54/ Rugged: Tested to MIL-STD-810G drop spec at 1 meter*/ Other Functions: 50,000 hours demonstrated/ Other Functions: Integrated Magnetic Stripe Reader (MSR), Integrated barcode reader (via rear facing auto focus camera), Integrated Smart Card Reader, Integrated Webcam (Front facing AF Camera) Optional Accessories Docking Station (E518363), VESA Bracket (E624438), Stylus (E761200), Additional Battery (E840851), Replacement Dock Cover (E108413) Replacement, Hand Strap (E697779), Replacement Power Supply (E452058)
