Scanner Zebra LS1203 1D

This bi-directional LS1203 handheld scanner handles all 1D barcodes and is ideal for small retailers. It delivers the functionality, features and reliability needed to improve operational efficiencies from the check-out line to the storeroom. It minimizes manual keying, ensures accuracy in all customer transactions, and it automates paper-based inventory processes. The device easily integrates multiple interfaces to help ensure connectivity to a host and PC system. Designed to meet the needs of small businesses, the LS1203 provides the performance and features needed to significantly reduce data entry errors and boost productivity day in and day out in gift shops, boutiques, sporting goods, jewelers, video stores, florists and other small local retailers.

Specifications

Scanners
Reading mode 1D
Scanning range/ Βάθος πεδίου 0.50 -12.50cm/ Metric: 0 - 19.68cm/ 0 - 21.50cm/ 0 - 21.50cm/ 0 - 26.00cm
Scanning range/ Width of Field Code 39 - 5 mil/ Code 39 - 7.5 mil/ Code 39 - 10 mil/ 100% UPC - 13mil/ 200% UPC - 26mil
Scan Rate Ρυθμός σάρωσης 100 scans per second
Interfaces USB, RS-232; Keyboard Wedge
Dimensions 2.4 in. H x 7.1 in. L x 2.4 in. W 6.2 cm H x 18 cm L x 6 cm W
Weight 4.3 oz. (122 g)
Ambient light Tolerant to typical artificial indoor and natural outdoor (direct sunlight) lighting conditions. Fluorescent, Incandescent, Mercury Vapor, Sodium Vapor, LED4: 450 Ft Candles (4,844 Lux) Sunlight: 8000 Ft Candles (86,111 Lux)
Sealing IP41
Symbologies UPC/EAN, UPC/EAN with Supplementals, UPC/EAN 128, Code 39, Code 39 Full ASCII, Code 39 TriOptic, Code 128, Code 128 Full ASCII, Codabar, nterleaved 2 of 5, Discrete 2 of 5, Code 93, MSI, Code 11, IATA, GS1 DataBar (formerly RSS) variants, Chinese 2 of 5
Additional features Operating Temp. 32° to 122° F/0° to 50° C/ Storage Temp.-40° to 158° F/-40° to 70° C/ Humidity: 5% to 95% relative humidity, non-condensing/ Drop Specs: Withstands multiple 5 ft./1.524m drops to concrete./ Voltage & Current:5 +/-10%VDC @ 100 mA (Stand by: <35 mA)
