Reading mode |
2D |
Scanning range/ Βάθος πεδίου |
Code 39 3.0 mil 1.5 in. / 3.8 cm 5.4 in / 13.7 cm, Code 39 5.0 mil 0 in. / 0 cm 11.0 in / 27.9 cm, PDF417 6.6 mil 1.1 in. / 2.8 cm 8.0 in / 20.3 cm, UPC 13.0 mil 0 in. / 0 cm 28.0 in / 71.1 cm, Data Matrix 10.0 mil 2.0 in / 5.1 cm 9.0 in / 22.9 cm, Code 39 20.0 mil 0 in / 0 cm 53.0 in / 134.6 cm, QR 10.0 mil 1.1 in./2.8 cm 8.5 in./21.6 cm, QR 20.0 mil 0.9 in./2.3 cm 16.2 in./41.1 cm |
Scanning range/ Width of Field |
Code 39 3.0 mil, Code 39 5.0 mil, PDF417 6.6 mil, UPC 13.0 mil, Data Matrix 10.0 mil, Code 39 20.0 mil, QR 10.0 mil, QR 20.0 mil. |
Resolution |
SR: Code 39 4 mil, UPC 60% 7.8 mil, PDF417 5 mil, Datamatrix 7.5 mil, HD: Code 39 3 mil, UPC 60% 7.8
mil, PDF417 4 mil, Datamatrix 5 mil
|
Interfaces |
USB, RS232, Keyboard Wedge, RS485 (IBM 46xx) , SSI
|
Dimensions |
6.48 in. H x 3.86 in. L x 2.64 in. W/ (16.5 cm H x 9.8 cm L x 6.7 cm W)
|
Weight |
5.71 oz. / 162 g |
Ambient light |
Immune to normal indoor lighting up to 1600 Lux; immune to sunlight up to 86,000 Lux
|
Sealing |
IP42 |
Symbologies |
1-D: UPC/EAN, UPC/EAN with supplementals, Bookland EAN, ISSN, UCC Coupon Extended
Code, Code 128, GS1-128, ISBT , 128, Code 39, Code 39 Full ASCII, Trioptic Code 39, Code 32, Code
93, Code 11, Matrix 2 of 5, Interleaved 2 of 5, Discrete 2 of 5, Codabar, MSI, Chinese 2 of 5, GS1 DataBar variants, Korean 3 of 5, ISBT Concat. 2-D: PDF417, MicroPDF417, Composite Codes, TLC-39, Data Matrix, Maxicode, QR Code, MicroQR, Aztec, Han Xin.Postal: Australian Post, US PLANET, Royal Mail 4 State Customer, US POSTNET, KIX Code (Dutch), UK Postal, Japan Post, UPU 4 State Postal FICS (Post US4), USPS 4 State Postal (Post US3), Canadian Post (Postbar). |
Additional features |
Operating Temp. 32° F to 122° F/0° C to 50° C/ Storage Temp. -40° F to 158° F/-40° C to 70° C/ Humidity 5% to 95%, non-condensing/ Drop Specification Withstands multiple 6 ft./1.83 m
drops to concrete.
|
