Xenon 1900 2D Scanner

Xenon 1900 2D Scanner

Downloads

File	Size	Download
ms-1900-xenon-ms-1900_xenon_2d.pdf	929.78KB	Download

Description

Scanner Honeywell Xenon 1900 2D

The Xenon™ 1900 series, featuring sixth-generation Adaptus™ area-imaging technology, has redefined the standard for handheld scanners. Custom sensor that’s optimized for aggressive barcode scanning, the Xenon series offers industry-leading performance and reliability for a wide variety of data collection applications. The Xenon 1900 series offers industry-leading performance and reliability to boost workflow performance in a wide variety of applications that require the versatility of area-imaging technology. Powered by Adaptus Imaging Technology 6.0.

HONEYWELL

Specifications

Scanners
Reading mode	2D
Scanning range/ Βάθος πεδίου	STANDARD RANGE (SR) :27.9 mm – 134.6 mm (1.1 in – 5.3 in)/ 10.2 mm – 439.4 mm (0.4 in – 17.3 in)/ 12.7 mm – 584.2 mm (0.5 in – 23.0 in)/ 10.2 mm – 154.9 mm (0.4 in – 6.1 in)/ 12.7 mm – 190.5 mm (0.5 in – 7.5 in)/ 15.2 mm – 383.5 mm (0.6 in – 15.1 in)
Scanning range/ Width of Field	5 mil code 39/ 13 mil UPC/ 20 mil Code 39/ 6.7 mil PDF417 / 10 mil DM/ 20 mil QR
Resolution	STANDARD RANGE (SR): Resolution 1D Code 39: 5 mil (0.127 mm)/ Resolution 2D DM: 6.7 mil (0.170 mm)
Interfaces	USB, Keyboard Wedge, RS-232, IBM 46xx (RS485)
Dimensions	104 mm x 71 mm x 160 mm (4.1 in x 2.8 in x 6.3 in)
Weight	147 g (5.2 oz)
Ambient light	100,000 lux
Sealing	IP41
Symbologies	Reads standard 1D, PDF, 2D, Postal and OCR symbologies
Additional features	Input Voltage: 4.0V DC to 5.5V DC. Operating Power: 2.3 W (450 mA @ 5V DC). Standby Power: 0.45 W (90 mA @ 5V DC) Operating Temperature: 0°C to 50°C (32°F to 122°F). Storage Temperature: -40°C to 70°C (-40°F to 158°F). Humidity: 0% to 95% relative humidity, non-condensing. Drop: Designed to withstand 50 1.8 m (6 ft) drops to concrete. Warranty: Five-year factory warranty
