HH360 Youjie 1D Scanner

HH360 Youjie 1D Scanner
HH360 Youjie 1D Scanner
HH360 Youjie 1D Scanner
HH360 Youjie 1D Scanner
HH360 Youjie 1D Scanner
HH360 Youjie 1D Scanner
HH360 Youjie 1D Scanner

Downloads

File Size Download
honeywell_hh360.pdf 180.38KB Download

Scanner Honeywell MS1250 Voyager 1D

Linear-Imaging Scanner with balanced performance, durability and ergonomics, meeting the scanning needs for switching between traditional printed barcodes and on-screen barcodes. HH360 provides scanning performance in scan intensive or light industrial applications as well. With its excellent linear imaging scanning performance and versatility, HH360 provides fast (scanning speed up to 300 scans/s), 1D image scanning capability for typical barcodes (up to 23.4 inches (600mm) scanning distance), high density barcodes, or even poor or damaged barcodes with a single device. It also enables easy scanning on all linear barcodes presented on screen, without any need to buy a specific scanner. Being highly durable and wearable, HH360 linear-imaging scanner is one of the toughest general duty scanners on the market, designed to keep your operation running smoothly. HH360 is the ideal choice for customers who value high scanning performance and durability of hand-held linear imaging scanner.

Specifications

Scanners
Reading mode 1D
Scanning range/ Βάθος πεδίου 4mil Code39 85mm – 155mm/ 5mil Code39 75mm – 200mm/ 7.5mil Code39 55mm – 315mm/ 10mil Code39 25mm – 415mm/ 13mil UPC-A 20mm – 500mm/ 20mil Code39 20mm – 650mm.
Scanning range/ Width of Field Pitch, Skew: 65° /75°. Minimum Width: 3 mil
Scan Rate Ρυθμός σάρωσης 300 scans/s
Interfaces USB, RS232, KBW
Dimensions 98mm×126mm×155mm
Weight 140g
Ambient light 70,000 Lux
Sealing IP40
Symbologies Reads all standard 1D and GS1 DataBarT M Symbologies
Additional features Operating Temperature: 0°C to 50°C/ Storage Temperature: -40°C to 60°C/ Humidity: 95%/ Drop: 1- 1.5m at random/ Input Voltage: 5 ± 0.5VDC/ Operating Power: 900mW, 180mA(Typical) @5VDC Standby/ Power: 500mW, 100mA(Typical)@5VDC
