EDA56 Handheld Computer

Name: EDA56 Handheld Computer
Brand: HONEYWELL
Price: 1.00 EUR
Availability: InStock

EDA56 Handheld Computer

Downloads

File	Size	Download
honeywell-scanpal-eda56-2pin-datasheet.pdf	104.01KB	Download
honeywell-scanpal-eda56-6pin-datasheet.pdf	109.02KB	Download

Description

Honeywell ScanPal EDA56 Wi-Fi6 Mobile Computer 2pin or 6pin

The Honeywell ScanPal™ EDA56 WLAN is a Wi-Fi 6 mobile computer that provides higher data rates and lower latency even in a densely connected environment. The EDA56’s design is ideal for retail, manufacturing, logistics, and public service applications. The EDA56 incorporates the all-new and powerful Honeywell S0703 scan engine, which enables fast reading of damaged or incomplete barcodes. Outfitted with a rugged housing and IP67 rated sealing, the EDA56 can operate under rough usage and demanding environmental conditions. A 4500mAh battery allows for prolonged and uninterrupted use between each charge. The battery is also easily removable and supports quick charge 3.0. The EDA56 is built on Android 11 and can be upgraded to Android 13 minimizing maintenance issues and ensuring long-term feature support. It is validated under AER (Android Enterprise Recommended) , a Google-led initiative that helps businesses confidently select, deploy, and manage Android devices and services best suited to their needs.

HONEYWELL

Specifications

Mobile Terminals
Monitor pda	5.5-inch, Gorilla Glass 5. High Definition Resolution 1440 x 720. Multi-touch capacitive (CTP), GFF. LED Backlight.
Operation System	Android 11, upgradable to Android 13
CPU pda	Qualcomm Snapdragon SM6115, Quad high-performance Kryo cores 2.0 GHz +Quadlow-power Kryo cores 1.8 GHz
Memory pda	4 GBRAM/64 GB Flash; 6 GB RAM/128 GB Flash
Communication	Bluetooth Class 5.1, WLAN, NFC, GPS
Interface-Ports	2 pin bottom connection, PC Interface USB 2.0 with Type-C or PC Interface: 6 pin bottom connection
Barcode scanner	1D/2D barcode Honeywell S0703 Slim Imager
Battery pda	Li-Ion, 3.8 V, 4,500 mAh removable. Charging Time: less than 3.5 hours. Battery Runtime: more than 12 hours
Keyboard	5 side keys for volume up/down, right and left scan keys and power on/off
Sealing	IP67
Resistance	Drop: 1.23 m (4.3 ft) to concrete. MIL-STD-810G under room temperature. 550 tumbles at 0.5m (1.64ft). Operating Temperature:-20°C to +50°C (-4°F to +122°F). Storage Temperature: -30°C to +70°C (-22°F to 158°F). Humidity: 5% to 90% (non-condensing)
Dimensions/ Weight pda	159 x 75 x 14.4 mm(6.26 in x 2.95 in x 0.57 in) Weight: 258gr
Accessories	Single Charging Home Base: Charges one terminal and one replaceable battery simultaneously. Backwards Adaptor Cup: Be compatible with EDA50/51 single charging dock. Standard Battery Pack. Quad Bay Battery Charger. RFID Bracket. Scan Handle. Rubber Boot. Wrist Strap. Hand Strap. Screen Film. Single Charging Dock: Charges one terminal. Quad Bay Charging Base: Charges four terminals simultaneously.
Additional features mobile terminals	Rear Camera 13-megapixel color camera. Front Camera 5-megapixel color camera. Storage Expansion: MicroSD (up to 128 GB). Real-Time Clock (RTC): 10 min back up vie super-cap. Sensors: acceleration sensor, light sensor, and proximity sensor. LED Battery Status Indicator. LED Scan Indication.
