File | Size | Download |
---|---|---|
ck3r-handheld-computer-data-sheet-en.pdf | 188.66KB | Download |
Φορητά Τερματικά | |
Οθόνη φορητού τερματικού | 8.9 cm (3.5 in) Transmissive QVGA, 240 x 320 pixels, 65,536 (16-bit RGB) colors. High-durability touch screen. LED backlight. Ambient light sensor. |
Λειτουργικό σύστημα | Microsoft Windows Embedded Handheld built on Windows 6.5.3 technology with Honeywell HTML5 Browser. Available via download at the Honeywell Developer Library |
CPU φορητού τερματικού | Power-efficient 1 GHz multi-engine Texas Instruments processor, 256 MB RAM and 512 MB Flash. |
Μνήμη φορητού τερματικού | Memory: 256 MB RAM, ROM: 512 MB. Customer-accessible micro SD slot for removable memory cards up to 32 GB |
Επικοινωνία | Wireless LAN: IEEE 802.11 b/g/n WLAN/ Security: Wi-Fi Certified for WPA and WPA2/ Authentication: 802.1x/ Cisco Compatibility: CCXv4/ Encryption: WEP (64- or 128-bit), AES, TKIP/ Bluetooth: Integrated Bluetooth Class II, Version 2.1+EDR/ Operating Channels: 0 to 78 (2402–2480 MHz)/ Data Rates: 1, 2, 3 Mbps/ Antenna: Internal. |
Συνδέσεις-θύρες | USB – Full Speed 2.0 OTG, USB – Full Speed 2.0 Client |
Barcode scanner | EA31 high-performance motion-tolerant 2D imager; (up to 400 in/s) white LED illumination. Capable of scanning all common 1D and 2D barcodes; 1D as small as 4 mils; 2D as small as 6.6 mils. Refer to User’s Manual for depth-of-field performance. |
Μπαταρία φορητού τερματικού | Battery Pack: Removable, rechargeable/ Included: User removable, rechargeable Lithium-Ion; 3.7V, 2000 mAh (7.4 watt-hours)/ Optional: Removable, rechargeable Lithium-Ion; 3.7V, 5100 mAh (18.5 watt-hours) /Optional: Removable, rechargeable Lithium-Ion; 3.7V, 5200 mAh (18.5 watt-hours) Smart Pack. |
Πληκτρολόγιο | Numeric with function keys/ Alphanumeric |
Στεγανοποίηση | IP54 |
Αντοχή | Withstands multiple 1.2 m (4 ft) drops to concrete/ Operating Temperature: -10°C to +50°C (+14°F to +122°F)/ Storage Temperature: -20°C to +70°C (-4°F to +158°F)/ Charging Temperature: +5°C to +35°C (+41°F to +95°F)/ Relative Humidity: Non-condensing, 95% |
Διαστάσεις/Βάρος φορητού τερματικού | L x W x D: 21.6 cm x 8.3 cm x 2.8 cm (8.53 in x 3.29 in x 1.12 in) Weight: 401 g (14.1 oz) with 2000 mAh battery Width: Grip Area: 6.1 cm (2.4 in) |
Αξεσουάρ | Supports most CK3 mobile computer charging and docking accessories as well as FlexDock modular docking system, vehicle dock and holder, snap-on adaptors and removable scan handle. |
